INFiLED achieves a significant breakthrough in LED technology by introducing Solid Skin Tech, an innovation designed to improve LED panels.

This new technology is primarily based on the GOB (Glue on Board) process.

Solid Skin Tech incorporates a sophisticated transparent adhesive that protects the surface of LED modules. This adhesive forms a solid protective layer, offering LEDs a reliable barrier against environmental elements such as moisture, dust, and physical impacts, enhancing their durability and lifespan. This is especially beneficial for LED modules that are regularly installed, dismantled, and transported, significantly reducing maintenance frequency and associated costs.

The Solid Skin Tech process consists of six key stages: LED panel aging, plasma cleaning, encapsulation, vacuum degassing, lamination, and CNC precision machining. This meticulous procedure ensures that products using Solid Skin Tech are made with high-quality materials, ensuring that the surfaces of LED panels are uniformly smooth and that the final product dimensions achieve a precision of ±0.02 mm.

Benefits of Solid Skin Technology

Solid Skin Tech offers three main advantages for LED display products:

• Enhanced screen protection: Ensures stable performance in various environments. The GOB process uses a high-quality resin adhesive to fill the LED module's bright surface, resulting in a strong protective layer. This advancement significantly increases the screen's resistance to moisture, static electricity, salt fog, dust, and oxidation.
• Increased impact resistance: The adhesive layer in the LED panels protects them from potential damage caused by vibrations or pressure during transport, installation, or disassembly. Tests performed by INFiLED's R&D team show that after four drops from a height of 1.2 meters, 23 LEDs packed inside a conventional module were damaged, while the module with Solid Skin Technology remained completely intact.
• Improved display quality: By applying GOB, the way light is emitted from LEDs changes from point emission to area emission. This transformation ensures consistent color representation and uniform brightness across the screen. Additionally, it effectively minimizes moiré patterns, enabling comfortable close viewing while providing a clear screen with soft, subtle colors.



Products using Solid Skin Technology

Currently, Solid Skin Technology is employed in several product lines. In rental applications, it is used in the energy-efficient GXmk2 series and the high-contrast DB series, designed for virtual production.

Conclusion

In summary, Solid Skin Technology is set to revolutionize the performance and reliability of INFiLED displays, making them a highly sought-after option for a wide range of applications, from commercial screens to large-scale events and installations.

The combination of greater durability, outstanding image quality, and a commitment to user convenience positions INFiLED as a leader in the competitive display technology landscape.
